TCG 2015 V6

Watercooled V6 with turbocharging, charge air cooling and four-valve technology.
Complete gas train and engine monitoring system for natural gas operation.
Individual cylinder heads, wet cylinder liners, long oil change intervals and easy changing of the engine fluids reduce the running and service costs and increase the availability of the machinery.
Easy installation: Turn-key solution with single cooling circuit and low space claim due to the very compact engine design.
Gear driven fan-hub and flexible cooling options lead to reduced maintenance and installastion costs.
Strong base engine well proved in many applications under toughest conditions.

Technical data
Emission norms US EPA 40CFR60
Number of cylinders 6
Bore 132 mm
Stroke 145 mm
Displacement 11.9 l
Typical generator power at 50 Hz / 1500 rpm
Typical generator power (COP) 153 kW
Typical generator power (PRP) 164 kW
Typical generator power at 60 Hz / 1800 rpm
Typical generator power (COP) 162 kW
Typical generator power (PRP) 180 kW
Length 1410 mm
Width 1110 mm
Height 1745 mm
Weight 995 kg
